T4CB120 – T Series Taper Roller Bearings

T4CB120 Bearing

Top T4CB120 T-Series Taper Roller Bearings from Amigo, China’s leading supplier. Precision-engineered, 120x170x27mm, with 164kN dynamic load capacity. Ideal for industrial applications like mining and metallurgy. High-quality, durable, and interchangeable with SKF, NSK, Koyo. Contact Amigo for reliable, cost-effective bearing solutions.

T4CB120 interchange ZVL T4CB120
T4CB120 cross reference ZVL T4CB120
T4CB120 Equivalent bearing interchange guide:
Price:enquiry
Model Number:T4CB120

Explore the T4CB120 - T Series Taper Roller Bearings Catalogue

B25 mm
T27 mm
a34,5 mm
C19,5 mm
d120 mm
D170 mm
Da min157 mm
da max130 mm
db min132 mm
Weight1,7 Kg
Db min.164 mm
ra max.3 mm
r1 min.3 mm
r2 min.3 mm
Da max.157 mm
Size (mm)120x170x27
Width (mm)27
Bearing numberT4CB120
Bore Diameter (mm)120
Outer Diameter (mm)170
Calculation factor (e)0,47
Calculation factor (Y)1,3
(Oil) Lubrication Speed2 600 r/min
(Grease) Lubrication Speed2 000 r/min
Basic dynamic load rating (C)154 kN
Basic static load rating (C0)248 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our T4CB120 Bearings

Discover AMIGO’s T4CB120 T-Series Taper Roller Bearings, precision-crafted for industrial excellence. With a 120x170x27mm size and 164kN dynamic load capacity, they’re perfect for mining and metallurgy. Interchangeable with SKF, NSK, and Koyo, these durable bearings ensure reliability. Contact AMIGO today for high-quality, cost-effective solutions!

✅Precision-Engineered Bearings: AMIGO’s T4CB120 T-Series Taper Roller Bearings (120x170x27mm) offer high precision for industrial applications.
✅High Load Capacity: With a 164kN dynamic load capacity, they excel in demanding sectors like mining and metallurgy.
✅Interchangeable Compatibility: T4CB120 bearings are interchangeable with leading brands like SKF, NSK, and Koyo.
✅Reliable Supplier: Contact AMIGO, China’s trusted supplier, for durable, cost-effective bearing solutions.

T Series Taper Roller Bearings
