Trusted as one of the top producers in China, Amigo is committed to providing reliable and efficient linear motion bearings that elevate performance and productivity. When precision and quality matter, choose Amigo’s TW Type Linear Motion Bearings for industry-leading results.
TW Type Linear Motion Bearings are versatile components widely used across various industrial applications where precision and reliability are paramount.
| Item # | (dr) Shaft Diameter | (D) Outer Diameter | (L) Length | (B) Distance btwn Retaining Rings | (W) Retaining Ring Width | (D1) Retaining Ring Diameter | (C) Dynamic Load | (Co) Static Load | Configuration | Seal Type | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TW4 | 0.25 in | 0.5000 in | 0.750 in | 0.515 in | 0.0390 in | 0.4687 in | 60 lb | 80 lb | Standard Type | No Seals | |
| TW4UU | 0.25 in | 0.5000 in | 0.750 in | 0.515 in | 0.0390 in | 0.4687 in | 60 lb | 80 lb | Standard Type | Seals on Both Ends | |
| TW6 | 0.375 in | 0.6250 in | 0.875 in | 0.703 in | 0.0390 in | 0.5880 in | 95 lb | 120 lb | Standard Type | No Seals | |
| TW6UU | 0.375 in | 0.6250 in | 0.875 in | 0.703 in | 0.0390 in | 0.5880 in | 95 lb | 120 lb | Standard Type | Seals on Both Ends | |
| TW8 | 0.5000 in | 0.8750 in | 1.250 in | 1.032 in | 0.0459 in | 0.8209 in | 230 lb | 290 lb | Standard Type | No Seals | |
| TW8UU | 0.5000 in | 0.8750 in | 1.250 in | 1.032 in | 0.0459 in | 0.8209 in | 230 lb | 290 lb | Standard Type | Seals on Both Ends | |
| TW 8-OP | 0.5000 in | 0.8750 in | 1.250 in | 1.032 in | 0.0459 in | 0.8209 in | 230 lb | 290 lb | Open Type | No Seals | |
| TW 8 UU-OP | 0.5000 in | 0.8750 in | 1.250 in | 1.032 in | 0.0459 in | 0.8209 in | 230 lb | 290 lb | Open Type | Seals on Both Ends | |
| TW10 | 0.6250 in | 1.1250 in | 1.500 in | 1.112 in | 0.0559 in | 1.0590 in | 400 lb | 500 lb | Standard Type | No Seals | |
| TW10UU | 0.6250 in | 1.1250 in | 1.500 in | 1.112 in | 0.0559 in | 1.0590 in | 400 lb | 500 lb | Standard Type | Seals on Both Ends | |
| TW 10-OP | 0.6250 in | 1.1250 in | 1.500 in | 1.112 in | 0.0559 in | 1.0590 in | 400 lb | 500 lb | Open Type | No Seals | |
| TW 10 UU-OP | 0.6250 in | 1.1250 in | 1.500 in | 1.112 in | 0.0559 in | 1.0590 in | 400 lb | 500 lb | Open Type | Seals on Both Ends | |
| TW12 | 0.7500 in | 1.2500 in | 1.625 in | 1.272 in | 0.0559 in | 1.1760 in | 470 lb | 590 lb | Standard Type | No Seals | |
| TW12UU | 0.7500 in | 1.2500 in | 1.625 in | 1.272 in | 0.0559 in | 1.1760 in | 470 lb | 590 lb | Standard Type | Seals on Both Ends | |
| TW 12-OP | 0.7500 in | 1.2500 in | 1.625 in | 1.272 in | 0.0559 in | 1.1760 in | 470 lb | 590 lb | Open Type | No Seals | |
| TW 12 UU-OP | 0.7500 in | 1.2500 in | 1.625 in | 1.272 in | 0.0559 in | 1.1760 in | 470 lb | 590 lb | Open Type | Seals on Both Ends | |
| TW16 | 1.0000 in | 1.5625 in | 2.250 in | 1.886 in | 0.0679 in | 1.4687 in | 850 lb | 1060 lb | Standard Type | No Seals | |
| TW16UU | 1.0000 in | 1.5625 in | 2.250 in | 1.886 in | 0.0679 in | 1.4687 in | 850 lb | 1060 lb | Standard Type | Seals on Both Ends | |
| TW 16-OP | 1.0000 in | 1.5625 in | 2.250 in | 1.886 in | 0.0679 in | 1.4687 in | 850 lb | 1060 lb | Open Type | No Seals | |
| TW 16 UU-OP | 1.0000 in | 1.5625 in | 2.250 in | 1.886 in | 0.0679 in | 1.4687 in | 850 lb | 1060 lb | Open Type | Seals on Both Ends | |
| TW20 | 1.2500 in | 2.0000 in | 2.625 in | 2.011 in | 0.0679 in | 1.8859 in | 1230 lb | 1530 lb | Standard Type | No Seals | |
| TW20UU | 1.2500 in | 2.0000 in | 2.625 in | 2.011 in | 0.0679 in | 1.8859 in | 1230 lb | 1530 lb | Standard Type | Seals on Both Ends | |
| TW 20-OP | 1.2500 in | 2.0000 in | 2.625 in | 2.011 in | 0.0679 in | 1.8859 in | 1230 lb | 1530 lb | Open Type | No Seals | |
| TW 20 UU-OP | 1.2500 in | 2.0000 in | 2.625 in | 2.011 in | 0.0679 in | 1.8859 in | 1230 lb | 1530 lb | Open Type | Seals on Both Ends | |
| TW24 | 1.5000 in | 2.3750 in | 3.000 in | 2.422 in | 0.0859 in | 2.2389 in | 1480 lb | 1850 lb | Standard Type | No Seals | |
| TW24UU | 1.5000 in | 2.3750 in | 3.000 in | 2.422 in | 0.0859 in | 2.2389 in | 1480 lb | 1850 lb | Standard Type | Seals on Both Ends | |
| TW 24-OP | 1.5000 in | 2.3750 in | 3.000 in | 2.422 in | 0.0859 in | 2.2389 in | 1480 lb | 1850 lb | Open Type | No Seals | |
| TW 24 UU-OP | 1.5000 in | 2.3750 in | 3.000 in | 2.422 in | 0.0859 in | 2.2389 in | 1480 lb | 1850 lb | Open Type | Seals on Both Ends | |
| TW32 | 2.0000 in | 3.0000 in | 4.000 in | 3.206 in | 0.1029 in | 2.8379 in | 2430 lb | 3040 lb | Standard Type | No Seals | |
| TW32UU | 2.0000 in | 3.0000 in | 4.000 in | 3.206 in | 0.1029 in | 2.8379 in | 2430 lb | 3040 lb | Standard Type | Seals on Both Ends | |
| TW 32-OP | 2.0000 in | 3.0000 in | 4.000 in | 3.206 in | 0.1029 in | 2.8379 in | 2430 lb | 3040 lb | Open Type | No Seals | |
| TW 32 UU-OP | 2.0000 in | 3.0000 in | 4.000 in | 3.206 in | 0.1029 in | 2.8379 in | 2430 lb | 3040 lb | Open Type | Seals on Both Ends | |
No posts found!
Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.
Smooth and easy functionality in numerous machines and mechanical systems is ensured by roller bearings which support friction. Obtaining the right type of roller bearing is imperative for long-lasting...
From the automotive to aerospace and manufacturing industries, roller bearings are used in countless machines because they serve to reduce friction and carry loads. With so many varieties of...
It is said that great things come in small packages, and this holds for the world of machinery. If used properly, even the smallest of components, such as bearings...
Every part of heavy-duty machinery is vital to its seamless functioning and flawless performance. Taper roller bearings are some of the critical components that keep it working under extreme...
Without a doubt, roller bearings are some of the most important elements in the majority of machines and industries today. Choosing the proper type of roller bearings is critical...
Cylindrical roller bearing is one of the most pivotal parts of many machines and are well known for their capability to manage hefty radial loads and achieve high rotational...
Bearings are essential components in countless mechanical systems, facilitating smooth and efficient motion while minimizing friction between moving parts. Among the vast array of bearing designs, plain bearings and...
From various mechanical systems we can highlight that roller bearings are crucial parts which help smoothen the motion and reduces the friction of parts that are movable. Roller bearings...
At AMIGO, we specialize in delivering reliable and high-performance TW Type Linear Motion Bearings for a variety of applications. Whether your project demands precision, durability, or efficiency, our bearings are designed to meet the highest standards of quality. Take the next step and streamline your operations by requesting a quote today. Our team is ready to assist you in finding the perfect solution for your needs. Contact us now to get started!
A: TW Type Linear Motion Bearings are high-precision components designed to provide smooth, low-friction linear motion in various applications. They are commonly used in machinery, automation systems, and industrial equipment.
A: These bearings are typically made from high-quality materials such as stainless steel or alloy steel, which ensure durability, corrosion resistance, and long-term performance.
A: They are widely used in applications like CNC machines, 3D printers, robotic arms, conveyor systems, and other systems requiring precise linear motion.
A: Unlike traditional rotary bearings, TW Type Linear Motion Bearings facilitate straight-line motion while minimizing friction, making them ideal for applications requiring accurate positioning and smooth movement.
A: Regular cleaning and lubrication with appropriate oils or greases are crucial to maintain optimum performance and extend the lifespan of the bearings.
A: Yes, these bearings are available in a variety of sizes and configurations to accommodate diverse application needs and load capacities.
A: They offer precise motion control, reduced wear and tear, increased efficiency, and low operational noise, making them a preferred choice for many engineers and manufacturers.
A: TW Type Linear Motion Bearings can be purchased through trusted industrial component suppliers, manufacturers like Amigo, or online platforms specializing in engineering and automation products.
