T2EE100 – T Series Taper Roller Bearings

T2EE100 Bearing

T2EE100 T Series Taper Roller Bearings from Amigo, China's top supplier. Designed for heavy radial and thrust loads, these metric bearings offer high durability and precision. Available at competitive prices with fast shipping. Order now from our trusted factory for reliable performance.

T2EE 100 interchange SKF T2EE 100
T2EE 100 cross reference SKF T2EE 100
T2EE 100 Equivalent bearing interchange guide:
Price:enquiry
Model Number:T2EE 100

Explore the T2EE100 - T Series Taper Roller Bearings Catalogue

T47 mm
a35 mm
C39 mm
B46 mm
d100 mm
D165 mm
series:T2EE
CategoryRoller Bearings
Inventory0
Size (mm)165x100x47
cup width:39 mm
Width (mm)47
cone width:46 mm
flange type:Non-Flanged Cup
maximum rpm:4300 RPM
Mass bearing3.89 kg
d1129.7 mm
closure type:Open
Product GroupB04334
Limiting speed4300 r/min
assembly type:Cone & Cup
bore diameter:100 mm
Bearing numberT2EE 100
Reference speed2800 r/min
finish/coating:Uncoated
Dimension series2EE
Weight / Kilogram3.929
outside diameter:165 mm
Manufacturer NameSKF
Cb min.8 mm
da max.111 mm
Da max.152.5 mm
Bore Diameter (mm)165
Db min.157 mm
Ca min.7 mm
Da min.145 mm
db min.113.5 mm
ra max.3 mm
rb max.3 mm
Outer Diameter (mm)100
Calculation factor Y1.9
r3,4 min.3 mm
r1,2 min.3 mm
rb - max.2.5 mm
Calculation factor e0.31
Da - max.151 mm
Db - min.157 mm
ra - max.2.5 mm
da - max.111 mm
Cb - min.8 mm
Minimum Buy QuantityN/A
db - min.112 mm
Ca - min.7 mm
Da - min.145 mm
d1 ≈129.7 mm
static load capacity:480 kN
r1,2 - min.3 mm
r3,4 - min.3 mm
dynamic load capacity:314 kN
Calculation factor - Y1.9
Calculation factor - e0.31
Basic dynamic load rating C383 kN
operating temperature range:Maximum of +250 °F
Basic dynamic load rating - C314 kN
Fatigue load limit Pu52 kN
Calculation factor Y01.1
Calculation factor - Y01.1
Fatigue load limit - Pu53 kN
Basic static load rating C0480 kN
Basic static load rating - C0480 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our T2EE100 Bearings

Discover AMIGO’s T2EE100 T Series Taper Roller Bearings, engineered for heavy radial and thrust loads. As China’s leading supplier, we offer high-quality, durable bearings at competitive prices with fast shipping. Order now from our trusted factory to ensure reliable performance for your industrial needs.

✅High-Quality Bearings: AMIGO’s T2EE100 T Series Taper Roller Bearings are engineered for superior performance, handling heavy radial and thrust loads with precision and durability.
✅Trusted Chinese Supplier: As China’s leading supplier, AMIGO ensures top-tier quality and reliability from our established factory.
✅Competitive Pricing: Get T2EE100 bearings at cost-effective prices, making high performance affordable for industrial applications.
✅Fast and Reliable Shipping: Order now for quick delivery, ensuring your operations run smoothly without delays.

T Series Taper Roller Bearings
