M 88048/M 88010 – Inch Measurement Taper Roller Bearings

M 88048M 88010 Bearing

Experience unmatched precision and durability with M 88048/M 88010 Inch Taper Roller Bearings, expertly designed for superior radial and axial load management. Sourced from Amigo, a trusted leader in China, these bearings deliver reliable performance for demanding applications. Choose quality and efficiency. Order from Amigo today!

M88048/M88010 interchange KBC M88048/M88010
M88048/M88010 cross reference KBC M88048/M88010
M88048/M88010 Equivalent bearing interchange guide:
Price:enquiry
Model Number:M88048/M88010

Explore the M 88048/M 88010 - Inch Measurement Taper Roller Bearings Catalogue

D68.262 mm
d33.338 mm
T22.225 mm
B22.225 mm
C17.462 mm
a19.5 mm
Weight0.325 Kg
r1 min.0.8 mm
r3 min.1.5 mm
r4 min.1.5 mm
r2 min.0.8 mm
Size (mm)33.338x68.262x22.225
Width (mm)22.225
Bearing numberM88048/M88010
Bore Diameter (mm)33.338
Outer Diameter (mm)68.262
Calculation factor (e)0.55
Calculation factor (Y)1.1
(Oil) Lubrication Speed7500 r/min
(Grease) Lubrication Speed5300 r/min
Basic dynamic load rating (C)55,4 kN
Basic static load rating (C0)70,7 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our M 88048/M 88010 Bearings

Choose Amigo for M 88048/M 88010 Bearings, offering precision, durability, and efficient load management for demanding tasks. Sourced from a trusted Chinese supplier, these bearings deliver reliable, high-performance results. Ensure quality and efficiency in your applications. Act now and order your bearings from Amigo today!

✅Unmatched Precision: Experience exceptional accuracy with M 88048/M 88010 Bearings.
✅Reliable Durability: Built to last, these bearings handle tough tasks effortlessly.
✅Efficient Performance: Optimized for superior radial and axial load management.
✅Trusted Supplier: Amigo ensures quality and reliability for demanding applications.
