LM 503349/LM 503310 – Inch Measurement Taper Roller Bearings

LM 503349LM 503310 Bearing

Amigo, leading the suppliers from China, offers LM 503349/LM 503310 Inch Taper Roller Bearings. These bearings boost effectiveness and productivity in a facility's operations to meet the rigorous requirements of the automotive and industrial sectors. Get the most from demanding applications by choosing Amigo.

LM503349/LM503310 interchange KBC LM503349/LM503310
LM503349/LM503310 cross reference KBC LM503349/LM503310
LM503349/LM503310 Equivalent bearing interchange guide:
Price:enquiry
Model Number:LM503349/LM503310

Explore the LM 503349/LM 503310 - Inch Measurement Taper Roller Bearings Catalogue

D74.976 mm
d45.987 mm
T18 mm
B18 mm
C14 mm
a15.9 mm
Weight0.305 Kg
r1 min.3.6 mm
r3 min.1.6 mm
r4 min.1.6 mm
r2 min.3.6 mm
Size (mm)45.987x74.976x18
Width (mm)18
Bearing numberLM503349/LM503310
Bore Diameter (mm)45.987
Outer Diameter (mm)74.976
Calculation factor (e)0.4
Calculation factor (Y)1.5
(Oil) Lubrication Speed6000 r/min
(Grease) Lubrication Speed4500 r/min
Basic dynamic load rating (C)51,8 kN
Basic static load rating (C0)71,3 kN
