14136 A/14276 – Inch Measurement Taper Roller Bearings

14136 A14276 Bearing

The 14136 A/14276 Inch Measurement Taper Roller Bearings have high precision and durability making them perfect for high load use. They are reliable and fulfill a wide range of industrial requirements. Amigo, one of the top suppliers in China, provides high standard & certified bearing manufactured under strict quality control. Trust Amigo’s 14136 A/14276 bearings for consistent performance in your projects.

14136A/14276 interchange KOYO 14136A/14276
14136A/14276 cross reference KOYO 14136A/14276
14136A/14276 Equivalent bearing interchange guide:
Price:enquiry
Model Number:14136A/14276

Explore the 14136 A/14276 - Inch Measurement Taper Roller Bearings Catalogue

B26,721 mm
d34,925 mm
D69,012 mm
T26,982 mm
C15,875 mm
a22,6 mm
Db63 mm
Da60 mm
r min.0,8 mm
Weight0,387 Kg
db min38 mm
da min.40 mm
r2 min.1,2 mm
rb max.1,2 mm
ra max.0,8 mm
Size (mm)34.925x69.012x26.982
Width (mm)26,982
Bearing number14136A/14276
Bore Diameter (mm)34,925
Outer Diameter (mm)69,012
Calculation factor (e)0,38
(Oil) Lubrication Speed7800 r/min
Calculation factor (Y0)0,86
(Grease) Lubrication Speed5900 r/min
Basic dynamic load rating (C)46,1 kN
Basic static load rating (C0)55 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our 14136 A/14276 Bearings

Get the reliable 14136 A/14276 Bearings from AMIGO, China’s top supplier. Known for precision and durability, these bearings excel in high-load applications. Don’t wait! Ensure top-notch performance for your projects today. Contact AMIGO or buy now to experience unmatched quality and dependability.

✅Reliable Bearings: 14136 A/14276 Bearings deliver unmatched precision and durability.
✅High-Load Performance: Designed to excel in demanding high-load applications.
✅Top Supplier Advantage: AMIGO is a trusted supplier, ensuring quality in every product.
✅Act Now: Buy or contact AMIGO today to secure exceptional bearings.
