NU2248 – 2200 Series Cylindrical Roller Bearings

NU2248 bearing

China’s leading supplier, Amigo, has the best quality NU2248 – 2200 cylindrical roller bearings. These bearings are made for various industries. With precision and reliability, Amigo uses expert engineering along with a high level of performance to ship absolutely trusted solutions that are tailor-made for the specific use and will stand up efficiently in harsh conditions.

NU2248 interchange NTN NU2248
NU2248 cross reference NTN NU2248
NU2248 Equivalent bearing interchange guide:
Price:enquiry
Model Number:NU2248

Explore the NU2248 - 2200 Series Cylindrical Roller Bearings Catalogue

ParameterDetails
F295 mm
d240 mm
D440 mm
B120 mm
C120 mm
E385 mm
Fw295 mm
Weight80 Kg
ra max3 mm
db min298 mm
rs min4 mm
Da max424 mm
da max293 mm
da min256 mm
r min.4 mm
r1a max3 mm
r1s min4 mm
r1 min.4 mm
CategoryRoller Bearings
Size (mm)240x440x120
Inventory0
Nlim (oil)1,600 rpm
Width (mm)120
Product GroupB04144
Nlim (grease)1,300 rpm
Bearing numberNU2248
Static load, C02,320 kN
Dynamic load, C1,440 kN
Manufacturer NameNTN
Weight / Kilogram81.5
Bore Diameter (mm)240
Outer Diameter (mm)440
Minimum Buy QuantityN/A
Fatigue limit load, Cu196 kN
Mass (without HJ ring)81.5 kg
Radial clearance classCN
(Grease) Lubrication Speed1 300 r/min
Basic static load rating (C0)2 320 kN
Basic dynamic load rating (C)1 440 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our NU2248 Bearings

Amigo provides excellent quality Nu2248 – 2200 Series Cylindrical Roller Bearings and is known for their accuracy, long product life, and adaptability to various applications. These expertly manufactured bearings are used in multiple industries, guaranteeing excellent, uninterrupted operations. Because of the premium quality solutions Amigo provides, they are a trusted partner for critical mechanical systems.

✅Premium Quality: Amigo provides top-grade NU2248 bearings built for durability and precision.
✅Smooth Performance: Ensures efficient mechanical processes with superior design features.
✅Versatile Applications: Ideal for various industries, ensuring adaptability to different needs.
✅Expert Engineering: Crafted with advanced technology for seamless, reliable operations.
