2200 Series Cylindrical Roller Bearings

Item #	(d) Bore Diameter	(D) Outside Diameter	(B) Width	(C) Dynamic Load	(Co) Static Load	Weight
NU2203 E	17 mm	40.000 mm	16 mm	23800 N	21600 N	0.09 kg
NU2204 E	20 mm	47 mm	18 mm	29700 N	27500 N	0.14 kg
NU2205 E	25 mm	52.000 mm	18 mm	34100 N	34000 N	0.17 kg
NU2206 E	30 mm	62 mm	20 mm	48400 N	49000 N	0.270 kg
NU2207 E	35 mm	72 mm	23 mm	59400 N	63000 N	0.42 kg
NU2208 E	40 mm	80.000 mm	23 mm	70400 N	75000 N	0.51 kg
NU2209 E	45 mm	85.000 mm	23 mm	73700 N	81500 N	0.55 kg
NU2210 E	50 mm	90 mm	23 mm	78100 N	88000 N	0.59 kg
NU2211 E	55 mm	100 mm	25 mm	99000 N	118000 N	0.82 kg
NU2212 E	60 mm	110.000 mm	28 mm	128000 N	153000 N	1.15 kg
NU2213 E	65.000 mm	120 mm	31 mm	147000 N	180000 N	1.50 kg
NU2214 E	70.000 mm	125.000 mm	31 mm	154000 N	193000 N	1.55 kg
NU2215 E	75.000 mm	130.000 mm	31 mm	161000 N	208000 N	1.65 kg
NU2216 E	80.000 mm	140.000 mm	33 mm	187000 N	245000 N	2.05 kg
NU2217 E	85.000 mm	150.000 mm	36 mm	216000 N	280000 N	2.55 kg
NU2218 E	90.000 mm	160.000 mm	40 mm	242000 N	315000 N	3.30 kg
NU2219 E	95.000 mm	170.000 mm	43 mm	286000 N	375000 N	4 kg
NU2220 E	100.000 mm	180.000 mm	46 mm	336000 N	450000 N	4.90 kg
NU2222 E	110.000 mm	200.000 mm	53 mm	380000 N	520000 N	7.00 kg
NU2224 E	120.000 mm	215 mm	58 mm	457000 N	630000 N	8.50 kg
NU2226 E	130 mm	230 mm	64 mm	528000 N	735000 N	10.50 kg
NU2228 E	140 mm	250 mm	68 mm	572000 N	830000 N	13.50 kg
NU2230 E	150 mm	270 mm	73 mm	627000 N	930000 N	19.50 kg
NU2232 E	160 mm	290 mm	80 mm	809000 N	1200000 N	24.50 kg
NU2234 E	170 mm	310 mm	86 mm	968000 N	1430000 N	30 kg
NU2236 E	180 mm	320 mm	86 mm	1010000 N	1500000 N	31.50 kg
NU2238 E	190 mm	340 mm	92 mm	1100000 N	1660000 N	39 kg
NU2240 E	200 mm	360 mm	98 mm	1230000 N	1900000 N	46 kg
NU2248	240 mm	440 mm	120 mm	1450000 N	2360000 N	84 kg
NU2252	260 mm	480 mm	130 mm	1790000 N	3000000 N	110.00 kg
NU2256	280 mm	500 mm	130 mm	2200000 N	3250000 N	115 kg
NU2260	300 mm	540 mm	140 mm	2090000 N	3450000 N	145.00 kg
NU2264	320 mm	580 mm	150 mm	2380000 N	4000000 N	180 kg
NU2268	340 mm	620 mm	165 mm	2640000 N	4500000 N	225 kg
NU2272	360 mm	650 mm	170 mm	2920000 N	4900000 N	255 kg
NU2276	380 mm	680 mm	175 mm	3140000 N	5500000 N	285.00 kg
NU2292	460 mm	830 mm	212 mm	5120000 N	8650000 N	530 kg

Item #

(d) Bore Diameter

(D) Outside Diameter

(B) Width

(Co) Static Load

Weight

NU2203 E

17 mm

40.000 mm

16 mm

23800 N

21600 N

0.09 kg

NU2204 E

20 mm

47 mm

18 mm

29700 N

27500 N

0.14 kg

NU2205 E

25 mm

52.000 mm

18 mm

34100 N

34000 N

0.17 kg

NU2206 E

30 mm

62 mm

20 mm

48400 N

49000 N

0.270 kg

NU2207 E

35 mm

72 mm

23 mm

59400 N

63000 N

0.42 kg

NU2208 E

40 mm

80.000 mm

23 mm

70400 N

75000 N

0.51 kg

NU2209 E

45 mm

85.000 mm

23 mm

73700 N

81500 N

0.55 kg

NU2210 E

50 mm

90 mm

23 mm

78100 N

88000 N

0.59 kg

NU2211 E

55 mm

100 mm

25 mm

99000 N

118000 N

0.82 kg

NU2212 E

60 mm

110.000 mm

28 mm

128000 N

153000 N

1.15 kg

NU2213 E

65.000 mm

120 mm

31 mm

147000 N

180000 N

1.50 kg

NU2214 E

70.000 mm

125.000 mm

31 mm

154000 N

193000 N

1.55 kg

NU2215 E

75.000 mm

130.000 mm

31 mm

161000 N

208000 N

1.65 kg

NU2216 E

80.000 mm

140.000 mm

33 mm

187000 N

245000 N

2.05 kg

NU2217 E

85.000 mm

150.000 mm

36 mm

216000 N

280000 N

2.55 kg

NU2218 E

90.000 mm

160.000 mm

40 mm

242000 N

315000 N

3.30 kg

NU2219 E

95.000 mm

170.000 mm

43 mm

286000 N

375000 N

4 kg

NU2220 E

100.000 mm

180.000 mm

46 mm

336000 N

450000 N

4.90 kg

NU2222 E

110.000 mm

200.000 mm

53 mm

380000 N

520000 N

7.00 kg

NU2224 E

120.000 mm

215 mm

58 mm

457000 N

630000 N

8.50 kg

NU2226 E

130 mm

230 mm

64 mm

528000 N

735000 N

10.50 kg

NU2228 E

140 mm

250 mm

68 mm

572000 N

830000 N

13.50 kg

NU2230 E

150 mm

270 mm

73 mm

627000 N

930000 N

19.50 kg

NU2232 E

160 mm

290 mm

80 mm

809000 N

1200000 N

24.50 kg

NU2234 E

170 mm

310 mm

86 mm

968000 N

1430000 N

30 kg

NU2236 E

180 mm

320 mm

86 mm

1010000 N

1500000 N

31.50 kg

NU2238 E

190 mm

340 mm

92 mm

1100000 N

1660000 N

39 kg

NU2240 E

200 mm

360 mm

98 mm

1230000 N

1900000 N

46 kg

NU2248

240 mm

440 mm

120 mm

1450000 N

2360000 N

84 kg

NU2252

260 mm

480 mm

130 mm

1790000 N

3000000 N

110.00 kg

NU2256

280 mm

500 mm

130 mm

2200000 N

3250000 N

115 kg

NU2260

300 mm

540 mm

140 mm

2090000 N

3450000 N

145.00 kg

NU2264

320 mm

580 mm

150 mm

2380000 N

4000000 N

180 kg

NU2268

340 mm

620 mm

165 mm

2640000 N

4500000 N

225 kg

NU2272

360 mm

650 mm

170 mm

2920000 N

4900000 N

255 kg

NU2276

380 mm

680 mm

175 mm

3140000 N

5500000 N

285.00 kg

NU2292

460 mm

830 mm

212 mm

5120000 N

8650000 N

530 kg
