NU215 E – 200 Series Cylindrical Roller Bearings

NU215 E

Amigo, a leading supplier from China, has NU215 E-200 Series Cylindrical Roller Bearings in stock. Well known for lasting long, performing efficiently at high speeds, and for their dependability, these bearings are made to serve in the most challenging industries and are designed for optimized productivity and value over time. Rely on Amigo for the best quality goods formulated to meet your precise operational challenges.

NU215 E interchange AST NU215 E
NU215 E cross reference AST NU215 E
NU215 E Equivalent bearing interchange guide:
Price:enquiry
Model Number:NU215 E

Explore the NU215 E - 200 Series Cylindrical Roller Bearings Catalogue

ParameterDetails
Material52100 Chrome steel, or equivalent
Size (mm)75x130x25
PrecisionRBEC 1
Width (B)25
Weight (g)1,300.00
Width (mm)25
Bearing TypeNU
Bore Dia (d)75
Outer Dia (D)130
Bearing numberNU215 E
Radius (min) (rs)1.5
Bore Diameter (mm)75
Standard ClearanceC0
Outer Diameter (mm)130
Static Load Rating (Cor)156,000
Dynamic Load Rating (Cr)130,000
Max Speed (Oil) (X1000 RPM)6
Max Speed (Grease) (X1000 RPM)5
Max. Shaft Shoulder Dia. Inner (Li)88.5
Min. Housing Shoulder Dia., Outer (Lo)118.5

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our NU215 E Bearings

Enhance your productivity using NU215 E Bearings from AMIGO, a leading supplier from China. Our bearings are known for their high quality, lasting life, and exceptional industrial accuracy. There is no need to wait anymore—improve your effectiveness right now! Place your orders at AMIGO for NU215 E Bearings and get them today!

✅ Trusted Supplier: Partner with AMIGO, a highly trusted bearings supplier in China.
✅ Unmatched Quality: Experience premium-quality NU215 E Bearings built for durability.
✅ Enhanced Performance: Achieve exceptional high-speed and industrial reliability effortlessly.
✅ Precision Engineering: Enjoy precision-engineered solutions tailored for your toughest challenges.
