Pick Amigo as your reliable source for 29300 Series Thrust Style Spherical Roller Bearings in China. Built for high-load applications, these bearings are used in the construction and mining industries. Amigo’s steadfast support and enduring quality guarantees your trust. Reach out to Amigo now to improve your industrial performance!
Reliable for mining, construction, and heavy industries, 29300 Series supports high loads and ensures smooth operations.
| Item # | (d) Bore Diameter | (D) Outer Diameter | (T) Height | (C) Dynamic Load | (Co) Static Load | (Grease) Lubrication Speed | (Oil) Lubrication Speed | (A) Minimum Load Factor |
|---|---|---|---|---|---|---|---|---|
| 29317 E | 85.000 mm | 150 mm | 39 mm | 334000 N | 1060000 N | 1600 r/min | 2200 r/min | 110 |
| 29318 E | 90.000 mm | 155 mm | 39 mm | 345000 N | 1080000 N | 1600 r/min | 2200 r/min | 110 |
| 29320 E | 100.000 mm | 170 mm | 42 mm | 408000 N | 1290000 N | 1500 r/min | 2000 r/min | 160 |
| 29322 E | 110.000 mm | 190 mm | 48 mm | 535000 N | 1730000 N | 1300 r/min | 1800 r/min | 280 |
| 29324 E | 120.000 mm | 210 mm | 54 mm | 656000 N | 2120000 N | 1100 r/min | 1600 r/min | 430 |
| 29326 E | 130 mm | 225 mm | 58 mm | 753000 N | 2500000 N | 1000 r/min | 1500 r/min | 590 |
| 29328 E | 140 mm | 240 mm | 60 mm | 845000 N | 2850000 N | 950 r/min | 1400 r/min | 770 |
| 29330 E | 150 mm | 250 mm | 60 mm | 863000 N | 2850000 N | 950 r/min | 1400 r/min | 770 |
| 29332 E | 160 mm | 270 mm | 67 mm | 1010000 N | 3450000 N | 850 r/min | 1200 r/min | 1100 |
| 29334 E | 170 mm | 280 mm | 67 mm | 1050000 N | 3550000 N | 850 r/min | 1200 r/min | 1200 |
| 29336 E | 180 mm | 300 mm | 73 mm | 1240000 N | 4300000 N | 800 r/min | 1100 r/min | 1800 |
| 29338 E | 190 mm | 320 mm | 78 mm | 1400000 N | 4750000 N | 750 r/min | 1000 r/min | 2100 |
| 29340 E | 200 mm | 340 mm | 85 mm | 1610000 N | 5500000 N | 700 r/min | 950 r/min | 2900 |
| 29344 E | 220 mm | 360 mm | 85 mm | 1730000 N | 6300000 N | 700 r/min | 950 r/min | 3800 |
| 29348 E | 240 mm | 380 mm | 85 mm | 1790000 N | 6550000 N | 670 r/min | 900 r/min | 4100 |
| 29352 E | 260 mm | 420 mm | 95 mm | 2220000 N | 8300000 N | 600 r/min | 800 r/min | 6500 |
| 29356 E | 280 mm | 440 mm | 95 mm | 2190000 N | 8650000 N | 600 r/min | 800 r/min | 7100 |
| 29360 E | 300 mm | 480 mm | 109 mm | 2670000 N | 10600000 N | 530 r/min | 700 r/min | 11000 |
| 29364 E | 320 mm | 500 mm | 109 mm | 2880000 N | 11200000 N | 500 r/min | 670 r/min | 12000 |
| 29368 | 340 mm | 540 mm | 122 mm | 2710000 N | 11000000 N | N/A | 600 r/min | 11000 |
| 29372 | 360 mm | 560 mm | 122 mm | 2760000 N | 11600000 N | N/A | 600 r/min | 13000 |
| 29376 | 380 mm | 600 mm | 132 mm | 3340000 N | 14000000 N | N/A | 530 r/min | 19000 |
| 29380 | 400 mm | 620 mm | 132 mm | 3450000 N | 14600000 N | N/A | 530 r/min | 20000 |
| 29384 | 420 mm | 650 mm | 140 mm | 3740000 N | 16000000 N | N/A | 500 r/min | 24000 |
| 29388 EM | 440 mm | 680 mm | 145 mm | 4490000 N | 19300000 N | N/A | 480 r/min | 35000 |
| 29392 | 460 mm | 710 mm | 150 mm | 4310000 N | 19000000 N | N/A | 450 r/min | 34000 |
| 29396 | 480 mm | 730 mm | 150 mm | 4370000 N | 19600000 N | N/A | 220 r/min | 36000 |
| 293/500 | 500 mm | 750 mm | 150 mm | 4490000 N | 20400000 N | N/A | 235 r/min | 40000 |
| 293/530 | 530 mm | 800 mm | 160 mm | 5230000 N | 23600000 N | N/A | 270 r/min | 53000 |
| 293/600 | 600 mm | 900 mm | 180 mm | 7530000 N | 34500000 N | N/A | 340 r/min | 110000 |
No posts found!
Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.
AMIGO gives you exceptional quality and performance with the AMIGO 29300 Series Thrust style Spherical Roller Bearings. These durable bearings are built for efficiency in highly demanding industries like construction or mining. Step up your machinery with AMIGO’s trusted engineering. Hurry up and contact AMIGO today to improve your industrial operations.
A: These bearings feature high load capacity, durable design, efficient performance, and low friction, ensuring superior reliability.
A: They are widely used in mining, construction, power generation, and industrial machinery for heavy-duty applications.
A: They provide excellent load handling, reduced wear, long service life, and improved machinery efficiency.
A: They are crafted with high-quality materials and advanced engineering to withstand extreme conditions and heavy loads.
A: Regular lubrication, timely inspections, and cleaning are essential to ensure optimal performance and durability.
A: Yes, these bearings are designed to manage combined axial and radial loads in demanding environments.
A: Yes, their design allows for smooth operation even at high speeds while reducing heat and wear.
A: AMIGO offers expert engineering, premium quality bearings, and customer-focused support for enhanced industrial performance.
