Amigo has best in class 7909CTDULP4 - 7900 Series Extra Light Duty Super Precision Angular Contact Ball Bearings. Their use in an industry relies on the accuracy of Amigo's Light Duty Bearings. Amigo, China’s top bearing supplier gets you performance enhancing bearings for your equipment.
| 7909 C interchange NSK 7909 C | |
| 7909 C cross reference NSK 7909 C | |
| 7909 C Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 7909 C |
| D | 68 mm |
|---|---|
| d | 45 mm |
| B | 12 mm |
| C | 12 mm |
| a | 13,6 mm |
| r min. | 0,6 mm |
| Weight | 0,129 Kg |
| Da max. | 63 mm |
| ra max. | 0,6 mm |
| r1 min. | 0,3 mm |
| da min. | 50 mm |
| Size (mm) | 45x68x12 |
| Width (mm) | 12 |
| Bearing number | 7909 C |
| Bore Diameter (mm) | 45 |
| Outer Diameter (mm) | 68 |
| (Oil) Lubrication Speed | 20 000 r/min |
| (Grease) Lubrication Speed | 14 000 r/min |
| Basic dynamic load rating (C) | 16 kN |
| Basic static load rating (C0) | 13,4 kN |
