SL Sheave Wheel Series Cylindrical Roller Bearings

Item #	(d) Bore Diameter	(D) Outer Diameter	(B) Width	(C) Dimension	(Cr) Basic Load Rating	(cor) Basic Load Rating	Limiting Speed	Mass
SL04 5008PP	40 mm	68 mm	38 mm	37 mm	79,000 N	125,000 N	2500	0.55 kg
SL04 5009PP	45 mm	75 mm	40 mm	39 mm	95,000 N	144,000 N	2200	0.70 kg
SL04 5010PP	50 mm	80 mm	40 mm	39 mm	99,500 N	158,000 N	2000	0.75 kg
SL04 5011PP	55 mm	90 mm	46 mm	45 mm	117,000 N	193,000 N	1800	1.15 kg
SL04 5012PP	60 mm	95 mm	46 mm	45 mm	123,000 N	208,000 N	1650	1.20 kg
SL04 5013PP	65.000 mm	100 mm	46 mm	45 mm	128,000 N	224,000 N	1500	1.30 kg
SL04 5014PP	70.000 mm	110 mm	54 mm	53 mm	170,000 N	285,000 N	1400	1.90 kg
SL04 5015PP	75.000 mm	115 mm	54 mm	53 mm	177,000 N	305,000 N	1350	2.00 kg
SL04 5016PP	80.000 mm	125 mm	60 mm	59 mm	250,000 N	430,000 N	1250	2.65 kg
SL04 5017PP	85.000 mm	130 mm	60 mm	59 mm	255,000 N	445,000 N	1150	2.80 kg
SL04 5018PP	90.000 mm	140 mm	67 mm	66 mm	305,000 N	540,000 N	1100	3.70 kg
SL04 5019PP	95.000 mm	145 mm	67 mm	66 mm	310,000 N	560,000 N	1050	3.9 kg
SL04 5020PP	100.000 mm	150 mm	67 mm	66 mm	315,000 N	585,000 N	1000	4.05 kg
SL04 5022PP	110.000 mm	170 mm	80 mm	79 mm	380,000 N	695,000 N	900	6.50 kg
SL04 5024PP	120.000 mm	180 mm	80 mm	79 mm	400,000 N	750,000 N	850	6.95 kg
SL04 5026PP	130 mm	200 mm	95 mm	94 mm	535,000 N	1,000,000 N	750	10.5 kg
SL04 5028PP	140 mm	210 mm	95 mm	94 mm	540,000 N	1,070,000 N	700	11 kg
SL04 5030PP	150 mm	225 mm	100 mm	99 mm	620,000 N	1,210,000 N	650	13.5 kg
SL04 5032PP	160 mm	240 mm	109 mm	108 mm	715,000 N	1,390,000 N	600	16.5 kg
SL04 5034PP	170 mm	260 mm	122 mm	121 mm	850,000 N	1,730,000 N	600	22.5 kg
SL04 5036PP	180 mm	280 mm	136 mm	135 mm	1,060,000 N	2,140,000 N	550	30.0 kg
SL04 5038PP	190 mm	290 mm	136 mm	135 mm	1,110,000 N	2,230,000 N	500	31.5 kg
SL04 5040PP	200 mm	310 mm	150 mm	149 mm	1,300,000 N	2,650,000 N	500	40.5 kg
SL04 5044PP	220 mm	340 mm	160 mm	159 mm	1,500,000 N	3,100,000 N	450	52.0 kg
SL04 5048PP	240 mm	360 mm	160 mm	159 mm	1,560,000 N	3,350,000 N	400	55.5 kg
SL04 5052PP	260 mm	400 mm	190 mm	189 mm	2,110,000 N	4,500,000 N	350	85.0 kg
SL04 5056PP	280 mm	420 mm	190 mm	189 mm	2,200,000 N	4,850,000 N	350	90.9 kg

Item #

(d) Bore Diameter

(D) Outer Diameter

(B) Width

(Cr) Basic Load Rating

(cor) Basic Load Rating

Limiting Speed

Mass

SL04 5008PP

40 mm

68 mm

38 mm

37 mm

79,000 N

125,000 N

2500

0.55 kg

SL04 5009PP

45 mm

75 mm

40 mm

39 mm

95,000 N

144,000 N

2200

0.70 kg

SL04 5010PP

50 mm

80 mm

40 mm

39 mm

99,500 N

158,000 N

2000

0.75 kg

SL04 5011PP

55 mm

90 mm

46 mm

45 mm

117,000 N

193,000 N

1800

1.15 kg

SL04 5012PP

60 mm

95 mm

46 mm

45 mm

123,000 N

208,000 N

1650

1.20 kg

SL04 5013PP

65.000 mm

100 mm

46 mm

45 mm

128,000 N

224,000 N

1500

1.30 kg

SL04 5014PP

70.000 mm

110 mm

54 mm

53 mm

170,000 N

285,000 N

1400

1.90 kg

SL04 5015PP

75.000 mm

115 mm

54 mm

53 mm

177,000 N

305,000 N

1350

2.00 kg

SL04 5016PP

80.000 mm

125 mm

60 mm

59 mm

250,000 N

430,000 N

1250

2.65 kg

SL04 5017PP

85.000 mm

130 mm

60 mm

59 mm

255,000 N

445,000 N

1150

2.80 kg

SL04 5018PP

90.000 mm

140 mm

67 mm

66 mm

305,000 N

540,000 N

1100

3.70 kg

SL04 5019PP

95.000 mm

145 mm

67 mm

66 mm

310,000 N

560,000 N

1050

3.9 kg

SL04 5020PP

100.000 mm

150 mm

67 mm

66 mm

315,000 N

585,000 N

1000

4.05 kg

SL04 5022PP

110.000 mm

170 mm

80 mm

79 mm

380,000 N

695,000 N

900

6.50 kg

SL04 5024PP

120.000 mm

180 mm

80 mm

79 mm

400,000 N

750,000 N

850

6.95 kg

SL04 5026PP

130 mm

200 mm

95 mm

94 mm

535,000 N

1,000,000 N

750

10.5 kg

SL04 5028PP

140 mm

210 mm

95 mm

94 mm

540,000 N

1,070,000 N

700

11 kg

SL04 5030PP

150 mm

225 mm

100 mm

99 mm

620,000 N

1,210,000 N

650

13.5 kg

SL04 5032PP

160 mm

240 mm

109 mm

108 mm

715,000 N

1,390,000 N

600

16.5 kg

SL04 5034PP

170 mm

260 mm

122 mm

121 mm

850,000 N

1,730,000 N

600

22.5 kg

SL04 5036PP

180 mm

280 mm

136 mm

135 mm

1,060,000 N

2,140,000 N

550

30.0 kg

SL04 5038PP

190 mm

290 mm

136 mm

135 mm

1,110,000 N

2,230,000 N

500

31.5 kg

SL04 5040PP

200 mm

310 mm

150 mm

149 mm

1,300,000 N

2,650,000 N

500

40.5 kg

SL04 5044PP

220 mm

340 mm

160 mm

159 mm

1,500,000 N

3,100,000 N

450

52.0 kg

SL04 5048PP

240 mm

360 mm

160 mm

159 mm

1,560,000 N

3,350,000 N

400

55.5 kg

SL04 5052PP

260 mm

400 mm

190 mm

189 mm

2,110,000 N

4,500,000 N

350

85.0 kg

SL04 5056PP

280 mm

420 mm

190 mm

189 mm

2,200,000 N

4,850,000 N

350

90.9 kg
