2300 Series Cylindrical Roller Bearings

Item #	(d) Bore Diameter	(D) Outside Diameter	(B) Width	(C) Dynamic Load	(Co) Static Load	Weight
NU2304	20 mm	52.000 mm	21 mm	41300 N	38000 N	0.22 kg
NU2305	25 mm	62 mm	24 mm	58100 N	55000 N	0.38 kg
NU2306	30 mm	72 mm	27 mm	73700 N	75000 N	0.55 kg
NU2307	35 mm	80.000 mm	31 mm	91300 N	98000 N	0.75 kg
NU2308	40 mm	90 mm	33 mm	112000 N	120000 N	0.98 kg
NU2309	45 mm	100 mm	36 mm	138000 N	153000 N	1.35 kg
NU2310	50 mm	110.000 mm	40 mm	161000 N	186000 N	1.80 kg
NU2311	55 mm	120 mm	43 mm	201000 N	232000 N	2.30 kg
NU2312	60 mm	130.000 mm	46 mm	224000 N	265000 N	2.85 kg
NU2313	65.000 mm	140.000 mm	48 mm	251000 N	290000 N	3.45 kg
NU2314	70.000 mm	150.000 mm	51 mm	275000 N	325000 N	4.15 kg
NU2315	75.000 mm	160.000 mm	55 mm	33000 N	400000 N	5.10 kg
NU2316	80.000 mm	170.000 mm	58 mm	358000 N	440000 N	5.95 kg
NU2317	85.000 mm	180.000 mm	60 mm	396000 N	490000 N	7.00 kg
NU2318	90.000 mm	190.000 mm	64 mm	440000 N	540000 N	8.15 kg
NU2319	95.000 mm	200.000 mm	67 mm	468000 N	585000 N	9.75 kg
NU2320	100.000 mm	215 mm	73 mm	583000 N	735000 N	12.50 kg
NU2322	110.000 mm	240 mm	80 mm	682000 N	9000000 N	17.00 kg
NU2324	120.000 mm	260 mm	86 mm	792000 N	1040000 N	24.50 kg
NU2326	130 mm	280 mm	93 mm	935000 N	1250000 N	30.50 kg
NU2328	140 mm	300 mm	102 mm	1050000 N	1430000 N	37.50 kg
NU2330	150 mm	320 mm	108 mm	1190000 N	1630000 N	46.50 kg
NU2332	160 mm	340 mm	114 mm	1320000 N	1860000 N	54.00 kg
NU2334	170 mm	360 mm	120 mm	1230000 N	1800000 N	63.00 kg
NU2336	180 mm	380 mm	126 mm	1400000 N	2040000 N	73.00 kg
NU2338	190 mm	400 mm	132 mm	1830000 N	2550000 N	82.50 kg
NU2340	200 mm	420 mm	138 mm	2850000 N	2850000 N	96.00 kg
NU2340	200 mm	420 mm	138 mm	2050000 N	2850000 N	96.00 kg
NU2344	220 mm	460 mm	145 mm	2330000 N	3250000 N	120.00 kg
NU2348	240 mm	500 mm	155 mm	2120000 N	3250000 N	155.00 kg
NU2356	280 mm	580 mm	175 mm	2700000 N	4300000 N	230.00 kg

Item #

(d) Bore Diameter

(D) Outside Diameter

(B) Width

(Co) Static Load

Weight

NU2304

20 mm

52.000 mm

21 mm

41300 N

38000 N

0.22 kg

NU2305

25 mm

62 mm

24 mm

58100 N

55000 N

0.38 kg

NU2306

30 mm

72 mm

27 mm

73700 N

75000 N

0.55 kg

NU2307

35 mm

80.000 mm

31 mm

91300 N

98000 N

0.75 kg

NU2308

40 mm

90 mm

33 mm

112000 N

120000 N

0.98 kg

NU2309

45 mm

100 mm

36 mm

138000 N

153000 N

1.35 kg

NU2310

50 mm

110.000 mm

40 mm

161000 N

186000 N

1.80 kg

NU2311

55 mm

120 mm

43 mm

201000 N

232000 N

2.30 kg

NU2312

60 mm

130.000 mm

46 mm

224000 N

265000 N

2.85 kg

NU2313

65.000 mm

140.000 mm

48 mm

251000 N

290000 N

3.45 kg

NU2314

70.000 mm

150.000 mm

51 mm

275000 N

325000 N

4.15 kg

NU2315

75.000 mm

160.000 mm

55 mm

33000 N

400000 N

5.10 kg

NU2316

80.000 mm

170.000 mm

58 mm

358000 N

440000 N

5.95 kg

NU2317

85.000 mm

180.000 mm

60 mm

396000 N

490000 N

7.00 kg

NU2318

90.000 mm

190.000 mm

64 mm

440000 N

540000 N

8.15 kg

NU2319

95.000 mm

200.000 mm

67 mm

468000 N

585000 N

9.75 kg

NU2320

100.000 mm

215 mm

73 mm

583000 N

735000 N

12.50 kg

NU2322

110.000 mm

240 mm

80 mm

682000 N

9000000 N

17.00 kg

NU2324

120.000 mm

260 mm

86 mm

792000 N

1040000 N

24.50 kg

NU2326

130 mm

280 mm

93 mm

935000 N

1250000 N

30.50 kg

NU2328

140 mm

300 mm

102 mm

1050000 N

1430000 N

37.50 kg

NU2330

150 mm

320 mm

108 mm

1190000 N

1630000 N

46.50 kg

NU2332

160 mm

340 mm

114 mm

1320000 N

1860000 N

54.00 kg

NU2334

170 mm

360 mm

120 mm

1230000 N

1800000 N

63.00 kg

NU2336

180 mm

380 mm

126 mm

1400000 N

2040000 N

73.00 kg

NU2338

190 mm

400 mm

132 mm

1830000 N

2550000 N

82.50 kg

NU2340

200 mm

420 mm

138 mm

2850000 N

96.00 kg

NU2340

200 mm

420 mm

138 mm

2050000 N

2850000 N

96.00 kg

NU2344

220 mm

460 mm

145 mm

2330000 N

3250000 N

120.00 kg

NU2348

240 mm

500 mm

155 mm

2120000 N

3250000 N

155.00 kg

NU2356

280 mm

580 mm

175 mm

2700000 N

4300000 N

230.00 kg
