310 – Maximum Capacity Series Deep Groove Radial Ball Bearings

310

310 - Maximum Capacity Series Deep Groove Radial Ball Bearings deliver outstanding durability, efficiency, and reliable performance. Designed for heavy-duty applications, they easily handle high loads while ensuring consistent, smooth operation. Built for long-lasting use, these bearings minimize downtime and optimize productivity, making them ideal for demanding industrial environments. With robust construction and dependable design, 310 - Maximum Capacity Series Deep Groove Radial Ball Bearings provide high-quality solutions for challenging applications.

310 interchange SKF 310
310 cross reference SKF 310
310 Equivalent bearing interchange guide:
Price:enquiry
Model Number:310

Explore the 310 - Maximum Capacity Series Deep Groove Radial Ball Bearings Catalogue

D110 mm
d50 mm
B27 mm
C27 mm
d168,7 mm
D295,2 mm
Bore1.969 Inch | 50 Millimeter
NounBearing
da max68,6 mm
UNSPSC31171504
Weight1,15 Kg
ra max.2 mm
Da max.99 mm
da min.61 mm
r2 min.2 mm
r1 min.2 mm
series:31
CategorySingle Row Ball Bearing
Size (mm)50x110x27
Snap RingNo
Inventory1
EnclosureOpen
Width (mm)27
bore type:Round
Weight / LBS2.62
maximum rpm:7000 RPM
Mass bearing1.15 kg
Cage MaterialSteel
Product GroupB00308
closure type:Open
Inch - MetricMetric
bore diameter:50 mm
Keyword StringBall
overall width:27 mm
cage material:Steel
fillet radius:2 mm
Bearing number310
Limiting speed7000 r/min
Reference speed11000 r/min
Rolling ElementBall Bearing
finish/coating:Uncoated
Precision ClassABEC 1 | ISO P0
Outside Diameter4.331 Inch | 110 Millimeter
Long Description50MM Bore; 110MM Outside Diameter; 27MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; No Snap Ring; No Internal Special Features
Outer Race Width1.063 Inch | 27 Millimeter
Manufacturer URLhttp://www.skf.com
Weight / Kilogram1.187
outer ring width:27 mm
Manufacturer NameSKF
precision rating:ABEC 3 (ISO Class 6)
outside diameter:110 mm
da?min.61 mm
Bore Diameter (mm)50
Da?max.99 mm
ra?max.2 mm
Internal ClearanceC0-Medium
Outer Diameter (mm)110
internal clearance:C0
Minimum Buy QuantityN/A
r1,2?min.2 mm
row type & fill slot:Single Row Filling Slot
static load capacity:52 kN
Harmonized Tariff Code8482.10.50.68
dynamic load capacity:64.4 kN
Fatigue load limit (Pu)2,2
Manufacturer Item Number310
Internal Special FeaturesNo
thrust application warning:This product can not be used in Thrust Applications
Basic dynamic load rating C64.4 kN
Basic dynamic load rating (C)64,4 kN
Basic static load rating (C0)52 kN
Maximum Capacity / Filling SlotYes
Fatigue load limit Pu2.2 kN
Calculation factor kr0.05
Basic static load rating C052 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our 310 Bearings

AMIGO 310 bearings solve complex problems for industrial applications with reliable performance, durability, and efficiency. They are adapted to take on large loads and are specially designed for heavy-duty work, enabling smooth, steady operation. Increased productivity and prolonged operational uptime, due to reduced downtime and sustained operational efficiency, make these bearings ideal for the most demanding functions. Outstanding infrastructure enables AMIGO 310 bearings to withstand harsh industrial conditions, delivering reliable and durable performance tailored to complex industrial requirements.

Exceptional Durability: AMIGO 310 Bearings are designed to withstand demanding industrial conditions for long-lasting performance.
Reliable Efficiency: These bearings ensure smooth, consistent operation, reducing downtime and maximizing productivity.
High Load Capacity: Specially crafted to handle heavy loads effortlessly in challenging industrial applications.
Tailored Solutions: Custom-designed to meet specific needs, offering dependable performance for rigorous operational demands.
