213 – Maximum Capacity Series Deep Groove Radial Ball Bearings

213

213 - Maximum Capacity Series Deep Groove Radial Ball Bearings operate supremely, maintaining high capacity and enduring exceptional wear. Able to withstand deep industrial applications, these bearings reduce and increase the performance of machinery throughout its lifecycle. 213 - Maximum Capacity Series Deep Groove Radial Ball Bearings ensure exceptional precision and reliability, guaranteeing enduring performance during complex mechanical procedures. They are unparalleled in productivity enhancement while providing durability and enduring performance.

213 interchange SKF 213
213 cross reference SKF 213
213 Equivalent bearing interchange guide:
Price:enquiry
Model Number:213

Explore the 213 - Maximum Capacity Series Deep Groove Radial Ball Bearings Catalogue

D120 mm
d65 mm
B23 mm
NounBearing
Bore2.559 Inch | 65 Millimeter
UNSPSC31171504
series:21
CategorySingle Row Ball Bearing
Inventory3
EnclosureOpen
Size (mm)120x65x23
Snap RingNo
Width (mm)23
bore type:Round
Weight / LBS2.38
Mass bearing1.05 kg
maximum rpm:6000 RPM
Inch - MetricMetric
Product GroupB00308
Cage MaterialSteel
closure type:Open
D2105.8 mm
d183.3 mm
Keyword StringBall
bore diameter:65 mm
cage material:Steel
fillet radius:1.5 mm
overall width:23 mm
Bearing number213
Limiting speed6000 r/min
Rolling ElementBall Bearing
finish/coating:Uncoated
Precision ClassABEC 1 | ISO P0
Reference speed10000 r/min
Manufacturer URLhttp://www.skf.com
Long Description65MM Bore; 120MM Outside Diameter; 23MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; No Snap Ring; No Internal Special Features
Outer Race Width0.906 Inch | 23 Millimeter
Outside Diameter4.724 Inch | 120 Millimeter
precision rating:ABEC 1 (ISO Class Normal)
outside diameter:120 mm
outer ring width:23 mm
Manufacturer NameSKF
Weight / Kilogram1.08
da?min.74 mm
Da?max.111 mm
Bore Diameter (mm)120
Internal ClearanceC0-Medium
ra?max.1.5 mm
internal clearance:C0
Outer Diameter (mm)65
snap ring included:Without Snap Ring
da?- min.74 mm
r1,2?min.1.5 mm
ra?- max.1.5 mm
Da?- max.111 mm
Minimum Buy QuantityN/A
static load capacity:58.5 kN
row type & fill slot:Single Row Filling Slot
r1,2?- min.1.5 mm
dynamic load capacity:60.5 kN
Harmonized Tariff Code8482.10.50.68
Manufacturer Item Number213
Internal Special FeaturesNo
thrust application warning:This product can not be used in Thrust Applications
Basic dynamic load rating C60.5 kN
Basic dynamic load rating - C60.5 kN
Maximum Capacity / Filling SlotYes
Fatigue load limit Pu2.5 kN
Calculation factor kr0.04
Fatigue load limit - Pu2.5 kN
Calculation factor - kr0.04
Basic static load rating C058.5 kN
Basic static load rating - C058.5 kN
