207 – Maximum Capacity Series Deep Groove Radial Ball Bearings

A Chinese supplier, Amigo, has introduced their new 207- Maximum Capacity Series Deep Groove Radial Ball Bearings. They are best suited for deep groove ball bearings with high load requirements, enduring precision, and exceptional durability. Trust Amigo for standards-compliant bearings that outlasts expectations, especially under heavy-duty operations.

207 interchange SKF 207
207 cross reference SKF 207
207 Equivalent bearing interchange guide:
Price:enquiry
Model Number:207

Explore the 207 - Maximum Capacity Series Deep Groove Radial Ball Bearings Catalogue

D72 mm
d35 mm
B17 mm
NounBearing
Bore1.378 Inch | 35 Millimeter
UNSPSC31171504
series:20
CategorySingle Row Ball Bearing
Inventory6
EnclosureOpen
Size (mm)72x35x17
Snap RingNo
Width (mm)17
bore type:Round
Weight / LBS0.7
Mass bearing0.31 kg
maximum rpm:10000 RPM
Inch - MetricMetric
Product GroupB00308
Cage MaterialSteel
closure type:Open
D262.69 mm
d146.94 mm
Keyword StringBall
bore diameter:35 mm
cage material:Steel
fillet radius:1 mm
overall width:17 mm
Bearing number207
Limiting speed10000 r/min
Rolling ElementBall Bearing
finish/coating:Uncoated
Precision ClassABEC 1 | ISO P0
Reference speed17000 r/min
Manufacturer URLhttp://www.skf.com
Long Description35MM Bore; 72MM Outside Diameter; 17MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; No Snap Ring; No Internal Special Features
Outer Race Width0.669 Inch | 17 Millimeter
Outside Diameter2.835 Inch | 72 Millimeter
precision rating:ABEC 3 (ISO Class 6)
outside diameter:72 mm
outer ring width:17 mm
Manufacturer NameSKF
Weight / Kilogram0.316
da min.42 mm
Bore Diameter (mm)72
Da max.65 mm
Internal ClearanceC0-Medium
ra max.1 mm
internal clearance:C0
Outer Diameter (mm)35
snap ring included:Without Snap Ring
da- min.42 mm
r1,2 min.1.1 mm
ra- max.1 mm
Da- max.65 mm
Minimum Buy QuantityN/A
static load capacity:22 kN
D2 ≈62.69 mm
d1 ≈46.94 mm
row type & fill slot:Single Row Filling Slot
r1,2 - min.1.1 mm
dynamic load capacity:27.5 kN
Harmonized Tariff Code8482.10.50.68
Manufacturer Item Number207
Internal Special FeaturesNo
thrust application warning:This product can not be used in Thrust Applications
Basic dynamic load rating C27.5 kN
Basic dynamic load rating - C27.5 kN
Maximum Capacity / Filling SlotYes
Fatigue load limit Pu0.93 kN
Calculation factor kr0.04
Fatigue load limit - Pu0.93 kN
Calculation factor - kr0.04
Basic static load rating C022 kN
Basic static load rating - C022 kN

Latest Blog Posts

Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.

Why Choose Our 207 Bearings

Premium 207 – Maximum Capacity Series Deep Groove Radial Ball Bearings and other products are readily available right now at Amigo, one of China’s most reputable suppliers. Experience unrivaled endurance, precision, and high load capacity for extreme applications. Don’t delay! Get unparalleled dependability today. Order now and experience top tier exceeds industry standards.

✅Premium Quality Bearings:Amigo introduces the 207 Maximum Capacity Series Bearings, further improving durability, precision, and load capacity.
✅Trusted Supplier in China:Bearing suppliers and manufacturers trust Amigo as a dependable source globally.
✅Performance for Demanding Applications: These products were designed to perform excellently even under rigorous, heavy-duty tasks.
✅Order Now: Get premium bearings tailored to your specifications by placing an order today.
