B500 Series Control Ball Bearings

Item #	Bore Diameter (mm)	Outside Diameter (mm)	Width (mm)	Dynamic Load (N)	Static Load (N)	Weight (kg)
NU202 E	15 mm	35.000 mm	11 mm	12500 N	10200 N	0.05 kg
NU203 E	17 mm	40.000 mm	12 mm	17200 N	14300 N	0.07 kg
NU204 E	20 mm	47 mm	14 mm	25100 N	22000 N	0.12 kg
NU205 E	25 mm	52.000 mm	15 mm	28600 N	27000 N	0.14 kg
NU206 E	30 mm	62 mm	16 mm	38000 N	36500 N	0.22 kg
NU207 E	35 mm	72 mm	17 mm	48400 N	48000 N	0.310 kg
NU208 E	40 mm	80.000 mm	18 mm	53900 N	53000 N	0.40 kg
NU209 E	45 mm	85.000 mm	19 mm	60500 N	64000 N	0.450 kg
NU210 E	50 mm	90 mm	20 mm	64400 N	69500 N	0.51 kg
NU211 E	55 mm	100 mm	21 mm	84200 N	95000 N	0.69 kg
NU212 E	60 mm	110.000 mm	22 mm	93500 N	102000 N	0.86 kg
NU213 E	65.000 mm	120 mm	23 mm	106000 N	118000 N	1.10 kg
NU214 E	70.000 mm	125.000 mm	24 mm	119000 N	137000 N	1.20 kg
NU215 E	75.000 mm	130.000 mm	25 mm	130000 N	156000 N	1.30 kg
NU216 E	80.000 mm	140.000 mm	26 mm	138000 N	166000 N	1.60 kg
NU217 E	85.000 mm	150.000 mm	28 mm	165000 N	200000 N	2 kg
NU218 E	90.000 mm	160.000 mm	30 mm	183000 N	220000 N	2.45 kg
NU219 E	95.000 mm	170.000 mm	32 mm	220000 N	265000 N	3 kg
NU220 E	100.000 mm	180.000 mm	34 mm	251000 N	305000 N	3.60 kg
NU221 E	105.000 mm	190.000 mm	36 mm	264000 N	315000 N	4.20 kg
NU222 E	110.000 mm	200.000 mm	38 mm	292000 N	365000 N	5 kg
NU224 E	120.000 mm	215 mm	40 mm	341000 N	430000 N	6 kg
NU226 E	130 mm	230 mm	40 mm	358000 N	455000 N	6.70 kg
NU228 E	140 mm	250 mm	42 mm	391000 N	510000 N	8.65 kg
NU230 E	150 mm	270 mm	45 mm	446000 N	600000 N	10.50 kg
NU232 E	160 mm	290 mm	48 mm	501000 N	680000 N	15.50 kg
NU234 E	170 mm	310 mm	52 mm	616000 N	815000 N	20.00 kg
NU236 E	180 mm	320 mm	52 mm	627000 N	850000 N	21 kg
NU238 E	190 mm	340 mm	55 mm	693000 N	965000 N	25.50 kg
NU240 E	200 mm	360 mm	58 mm	765000 N	1060000 N	29 kg
NU244	220 mm	400 mm	65 mm	765000 N	1080000 N	39.50 kg
NU248	240 mm	440 mm	72 mm	952000 N	1370000 N	53.50 kg
NU252	260 mm	480 mm	80 mm	1170000 N	1700000 N	71.00 kg
NU256	280 mm	500 mm	80 mm	1140000 N	1700000 N	73.00 kg
NU260	300 mm	540 mm	85 mm	1420000 N	2120000 N	89.50 kg
NU264	320 mm	580 mm	92 mm	1610000 N	2450000 N	115 kg

Item #

Bore Diameter (mm)

Outside Diameter (mm)

Width (mm)

Dynamic Load (N)

Static Load (N)

Weight (kg)

NU202 E

15 mm

35.000 mm

11 mm

12500 N

10200 N

0.05 kg

NU203 E

17 mm

40.000 mm

12 mm

17200 N

14300 N

0.07 kg

NU204 E

20 mm

47 mm

14 mm

25100 N

22000 N

0.12 kg

NU205 E

25 mm

52.000 mm

15 mm

28600 N

27000 N

0.14 kg

NU206 E

30 mm

62 mm

16 mm

38000 N

36500 N

0.22 kg

NU207 E

35 mm

72 mm

17 mm

48400 N

48000 N

0.310 kg

NU208 E

40 mm

80.000 mm

18 mm

53900 N

53000 N

0.40 kg

NU209 E

45 mm

85.000 mm

19 mm

60500 N

64000 N

0.450 kg

NU210 E

50 mm

90 mm

20 mm

64400 N

69500 N

0.51 kg

NU211 E

55 mm

100 mm

21 mm

84200 N

95000 N

0.69 kg

NU212 E

60 mm

110.000 mm

22 mm

93500 N

102000 N

0.86 kg

NU213 E

65.000 mm

120 mm

23 mm

106000 N

118000 N

1.10 kg

NU214 E

70.000 mm

125.000 mm

24 mm

119000 N

137000 N

1.20 kg

NU215 E

75.000 mm

130.000 mm

25 mm

130000 N

156000 N

1.30 kg

NU216 E

80.000 mm

140.000 mm

26 mm

138000 N

166000 N

1.60 kg

NU217 E

85.000 mm

150.000 mm

28 mm

165000 N

200000 N

2 kg

NU218 E

90.000 mm

160.000 mm

30 mm

183000 N

220000 N

2.45 kg

NU219 E

95.000 mm

170.000 mm

32 mm

220000 N

265000 N

3 kg

NU220 E

100.000 mm

180.000 mm

34 mm

251000 N

305000 N

3.60 kg

NU221 E

105.000 mm

190.000 mm

36 mm

264000 N

315000 N

4.20 kg

NU222 E

110.000 mm

200.000 mm

38 mm

292000 N

365000 N

5 kg

NU224 E

120.000 mm

215 mm

40 mm

341000 N

430000 N

6 kg

NU226 E

130 mm

230 mm

40 mm

358000 N

455000 N

6.70 kg

NU228 E

140 mm

250 mm

42 mm

391000 N

510000 N

8.65 kg

NU230 E

150 mm

270 mm

45 mm

446000 N

600000 N

10.50 kg

NU232 E

160 mm

290 mm

48 mm

501000 N

680000 N

15.50 kg

NU234 E

170 mm

310 mm

52 mm

616000 N

815000 N

20.00 kg

NU236 E

180 mm

320 mm

52 mm

627000 N

850000 N

21 kg

NU238 E

190 mm

340 mm

55 mm

693000 N

965000 N

25.50 kg

NU240 E

200 mm

360 mm

58 mm

765000 N

1060000 N

29 kg

NU244

220 mm

400 mm

65 mm

765000 N

1080000 N

39.50 kg

NU248

240 mm

440 mm

72 mm

952000 N

1370000 N

53.50 kg

NU252

260 mm

480 mm

80 mm

1170000 N

1700000 N

71.00 kg

NU256

280 mm

500 mm

80 mm

1140000 N

1700000 N

73.00 kg

NU260

300 mm

540 mm

85 mm

1420000 N

2120000 N

89.50 kg

NU264

320 mm

580 mm

92 mm

1610000 N

2450000 N

115 kg
