SM 60UU-AJ - SM Metric Type Linear Motion Bearings

Bearing Type	metal with bronze and graphite
Bearing number	AST850SM 6030
Bore Diameter (mm)	60
Outer Diameter (mm)	65
Wall Thickness (S3)	2.43
Average Clearance (Cd)	0.155
OD Chamfer Length (Co)	1.8
ID Chamfer Length (Ci)	0.6
Shaft Dia., Nominal (d)	60
ID Chamfer Angle (B deg.)	45
Bearing Length, Nominal (B)	30
Shaft Size (ds) - 60 +0 / -0.046	60 +0 / 0.046
Bearing Bore after Mounting (di)	60 +0.230 / +0.080
Bearing Outside Diameter, Nominal(Do)	65
Housing Bore Dia. (Dh) - 65 +0.030 / -0	65 +0.030 / 0
Bearing Length Tolerance (B tol.) - +0 / -0.40	0

Bearing Type

metal with bronze and graphite

Bearing number

AST850SM 6030

Bore Diameter (mm)

Outer Diameter (mm)

Wall Thickness (S3)

2.43

Average Clearance (Cd)

0.155

OD Chamfer Length (Co)

1.8

ID Chamfer Length (Ci)

0.6

Shaft Dia., Nominal (d)

ID Chamfer Angle (B deg.)

Bearing Length, Nominal (B)

Shaft Size (ds) - 60 +0 / -0.046

60 +0 / 0.046

Bearing Bore after Mounting (di)

60 +0.230 / +0.080

Bearing Outside Diameter, Nominal(Do)

Housing Bore Dia. (Dh) - 65 +0.030 / -0

65 +0.030 / 0

Bearing Length Tolerance (B tol.) - +0 / -0.40
