Explore 1300 Self Aligning Angular Contact Ball Bearings crafted with precision and reliability. As a leading supplier from China, we provide ISO-certified quality and cutting-edge solutions for sectors like aerospace, automotive, and heavy machinery. Trust our robust bearings to support demanding applications with consistency and excellence worldwide.
Built for demanding environments, 1300 Self Aligning Bearings excel in key industrial sectors requiring durability and precision:
| Item # | (d) Bore Diameter | (D) Outside Diameter | (B) Width | (C) Dynamic Load | (Co) Static Load | (Grease) Lubrication Speed | (Oil) Lubrication Speed | Tapered Bore No. | Adapter Sleeve No. |
|---|---|---|---|---|---|---|---|---|---|
| 135 | 5 mm | 19 mm | 6 mm | 2510 N | 480 N | 32000 r/min | 38000 r/min | N/A | N/A |
| 1301 | 12 mm | 37 mm | 12 mm | 2650 N | 560 N | 30000 r/min | 36000 r/min | N/A | N/A |
| 1302 | 15 mm | 42.000 mm | 13 mm | 3900 N | 815 N | 26000 r/min | 32000 r/min | N/A | N/A |
| 1303 | 17 mm | 47 mm | 14 mm | 5530 N | 1180 N | 24000 r/min | 30000 r/min | N/A | N/A |
| 1304 | 20 mm | 52.000 mm | 15 mm | 6240 N | 1430 N | 22000 r/min | 28000 r/min | 1304 EK | H 304 |
| 1305 | 25 mm | 62 mm | 17 mm | 7410 N | 1760 N | 19000 r/min | 24000 r/min | 1305 EK | H 305 |
| 1306 | 30 mm | 72 mm | 19 mm | 8840 N | 2200 N | 18000 r/min | 22000 r/min | 1306 EK | H 306 |
| 1307 | 35 mm | 80.000 mm | 21 mm | 12700 N | 3400 N | 15000 r/min | 18000 r/min | 1307 EK | H 307 |
| 1308 | 40 mm | 90 mm | 23 mm | 14300 N | 4000 N | 13000 r/min | 16000 r/min | 1308EK | H 308 |
| 1309 | 45 mm | 100 mm | 25 mm | 15600 N | 4650 N | 10000 r/min | 13000 r/min | 1309 EK | H 309 |
| 1310 | 50 mm | 110.000 mm | 27 mm | 19000 N | 6000 N | 9000 r/min | 11000 r/min | 1310 EK | H 310 |
| 1311 | 55 mm | 120 mm | 29 mm | 19900 N | 6950 N | 8500 r/min | 10000 r/min | 1311 EK | H 311 |
| 1312 | 60 mm | 130.000 mm | 31 mm | 22900 N | 7800 N | 7500 r/min | 9000 r/min | 1312 EK | H 312 |
| 1313 | 65.000 mm | 140.000 mm | 33 mm | 26500 N | 9150 N | 7000 r/min | 8500 r/min | 1313 EK | H 313 |
| 1314 | 70.000 mm | 150.000 mm | 35 mm | 27600 N | 10600 N | 6300 r/min | 7500 r/min | N/A | N/A |
| 1315 | 75.000 mm | 160.000 mm | 37 mm | 31200 N | 12200 N | 5600 r/min | 6700 r/min | 1315 K | H 315 |
| 1316 | 80.000 mm | 170.000 mm | 39 mm | 35100 N | 14000 N | 5300 r/min | 6300 r/min | 1316 K | H 316 |
| 1317 | 85.000 mm | 180.000 mm | 41 mm | 34500 N | 13700 N | 5000 r/min | 6000 r/min | 1317 K | H 317 |
| 1318 | 90.000 mm | 190.000 mm | 43 mm | 39000 N | 15600 N | 4800 r/min | 5600 r/min | 1318 K | H 318 |
| 1319 | 95.000 mm | 200.000 mm | 45 mm | 39700 N | 17000 N | 4500 r/min | 5300 r/min | 1319 K | H 319 |
| 1320 | 100.000 mm | 215 mm | 47 mm | 2510 N | 480 N | 32000 r/min | 38000 r/min | 1320 K | H 320 |
| 1322 | 110.000 mm | 240 mm | 50 mm | 9360 N | 2160 N | 18000 r/min | 22000 r/min | 1322 K | H 322 |
No posts found!
Maintain Inventiveness by Following The Blog for the Latest Best Practices, Techniques, Innovations, and Insights in the Field.
Experience unmatched precision with our 1300 Self Aligning Standard Angular Contact Ball Bearings. Designed to handle angular misalignments with ease, they offer robust construction for durability and consistent performance in industrial applications like heavy machinery, automotive, and agricultural equipment. Choose reliability and quality. Contact us today for tailored solutions to meet your needs!
A: These bearings provide high precision, self-aligning capability to handle angular misalignments, durable construction for long service life, and low friction for enhanced performance.
A: These bearings are widely used in automotive systems, heavy machinery, conveyor systems, and agricultural equipment, thanks to their durability and precision.
A: The self-aligning feature compensates for shaft misalignments, reducing mechanical stress, ensuring smooth operation, and extending the lifespan of the bearing and connected components.
A: Yes, these bearings are designed to perform effectively under varying loads, offering reliable support in dynamic and static applications.
A: Yes, these bearings can be customized to meet specific requirements, such as unique dimensions, materials, or coatings, ensuring optimal performance for your application.
A: Regular inspection, lubrication, and environmental protection measures should be conducted periodically. Follow manufacturer guidelines and consult technical support for detailed recommendations.
A: Use appropriate tools, avoid forceful mounting, and ensure alignment is within permissible limits to prevent premature failure and optimize performance.
A: Yes, the low friction design and advanced construction of these bearings allow for efficient and reliable performance in high-speed applications.
